제품 상세

Antibody

6.5 - 270 kDa 범위를 커버하는 3가지 컬러 밴드를 포함하며,
최대 100%까지의 transfer 효과를 개런티하는 Prestained protein ladder를 소개합니다.

특징



  • Muse Cell Analyzer는 일반적인 flow cytometry의 1/10 공간을 차지하는 microcapillary와 miniaturized optics을 사용하여 높은 성능의 cell 분석을 제공합니다.
  • Muse Cell Analyzer는 단계별 조작이 매우 간편하며, 누구나 쉽게 테스트를 실행할 수 있습니다.
  • 세포 준비 protocol을 압축하고 단순화하여 샘플 준비가 쉽고 빠릅니다.
  • Gating parameter와 threshold를 계산하는 소프트웨어 설정을 최적화 할 필요가 없습니다.
  • 소형 형광 검출기와 microcapillary 기술을 사용하여 정확하고 정밀하며, 정량적인 세포 분석이 가능합니다.
  • 최적화된 assay kit을 제공합니다.
  • 다양한 세포, 다양한 실험에 적용 가능합니다.




적용 분야

  • Count & Viability
  • Cell proliferation
  • Apoptosis
  • Cell signaling
  • Cell cycle
  • DNA damage
  • Autophagy
  • Immunology
  • Malaria research


사양

  • Input Cell Number : User selected; Cell concentration range of 10,000-500,000/mL
  • Sample Format : Single loader;
  • Cell Types : Homogeneous or heterogeneous, suspension or adherent, primary cells or cell lines
  • Cell Size : 2~60㎛ in diameter
  • Data Handling : Data analyzed on system, with USB export of graphs, CSV files, and raw data files
  • Instrument size : 20cm X 25cm


원리

  • 기존 유세포분석기의 1/10 사이즈로 제작된 microcapillary를 통해 흐르는 cell의 3가지 parameter (사이즈, yellow & red color)를 laser로 탐지합니다.





Case Study

  • 30개 suspension 및 adhrerent cell을 3회 반복 측정하였을때, Muse는 매뉴얼 hemocytometry 방법이나 image-based automated analysis에 비해 낮은 CV값을 보이며 cell viability를 더 정확하게 측정합니다.




  • 다수의 cell을 3회 반복 측정하였을때 Muse를 이용한 cell concentration 값은 다른 방식의 분석법에 비해 더 정확하고 균일하였습니다.







Muse Open Module



  • Muse Open Module 프로그램은 closed platform인 Guava Muse Cell Analyzer의 확장성을 위해 추가 설치되는 소프트웨어 입니다.
  • 기존 인터페이스의 심플함을 유지하면서 분석할 수 있는 범위를 확장하였습니다.
  • Red, Yellow 두 가지 module을 통해 보다 다양한 실험에 응용 가능합니다.
  • 세포 외부, 내부의 마커들의 dual color 분석 뿐만 아니라 red fluorescent proteins 분석을 제공합니다.
  • Green Laser와 yellow, red detector에 적합한 형광 dye 사용이 가능합니다.



Laser  Green : 532nm
Detector  Red : 680/30 nm
  Yellow : 576/28 nm





  • TUNEL Assay를 이용한 intracellular staining시 Muse Open Module로 분석


Intracellular staining of DNA DSBs in apoptotic Jurkat cells by TUNEL. Jurkat cells were induced with staurosporine at 0 (A), 0.1 µM (B), 0.3 µM (C), and 1 µM (D) for 4 hours at 37° C. The TUNEL assay was performed and data was acquired with the Muse® Open Module Yellow. The figure shows TUNEL-negative cells in blue and TUNEL-positive cells in red, with the optional histogram overlay of untreated cells in grey


  • RFP 분석_ Untransfection과 Transfection의 HEK293 세포의 비율 변화를 Open Module로 관찰


RFP analysis. Untransfected and RFP transfected HEK293 cells were mixed at 1:0 (A), 3:1 (B), 1:1 (C), 1:3 (D), and 0:1 (E) ratios. Data was acquired with the Muse® Open Module Yellow. The figure above shows untransfected HEK293 cells in blue and RFP transfected HEK-RFP cells in red, with the optional histogram overlay of 100% untransfected HEK293 cell sample in grey (B-E).


  • Muse Open Module을 이용한 Cell population의 dual color 분석



Dual color extracellular staining of cell subpopulations. Human whole blood was stained with anti-CD3 PE and anti-CD20 PE-Cy5 for acquisition with the Muse® Open Module Yellow (A), and PBMCs were stained with anti-CD3 PE-Cy5 and anti-CD4 PE for acquisition with the Muse Open Module Red (B).


Muse System 기기 유지관리 시약

Product Instrument Cat. No.
Muse® System Check Kit Muse® MCH100101
Instrument Cleaning Fluid (ICF) Guava®/Muse® 4200-0140





Flow Cytometer 선택 가이드



주문정보

주문정보 - Cat No, PRODUCT, SIZE, 수량 등 항목으로 구성되어있습니다.
  Product Cat.No. Size Maker Qty Data Sheet MSDS
